- Price:
- Request Quote
- Width:
- 50
- Length:
- 100
- Height:
- 18
- Roof Design Type:
- Double
- Roof Slope:
- 3:12
- Code:
- IBC 2009 Exposure C
- Seismic Category:
- 1
- Wind Load:
- 95 mph
- Roof Snow Load:
- 20 psf
- Stories:
- Ceiling Height:
- 18
- Live Load:
- 20 psf
50x100x18 NORTON, VA 24273 prefab steel building system for sale. See PDF file for details of the building and the extras included. Freight included to designated area. 770-781-8279 larry@lthsteelstructures.com
Engineering Design Info:
Building Type: Gabled Building
Width: 50′ Length: 100′ Height: 18′ Slope: 3:12
Sidewall Bay Config: 4 bays at 25 ft
Left Endwall: Non-expandable Bearing Frame Right Endwall: Non-expandable Bearing Frame
LEW Column Spacing: 15 / 20 / 15 REW Column Spacing: 15 / 20 / 15
LEW Girt: Flush REW Girt: Flush FSW Girt: Bypass BSW Girt: Bypass
Column Shape: Tapered
Code: IBC 2009 Wind Load: 95 Exposure: C
Live Load: 20 Reducible: Yes Ground Snow: 20 Roof Snow: 14
Seismic: Ss = 0.375 S1 = 0.121 Seismic Coefficient: 0.56 Collateral Load: 1
Snow Factors: Is = 1.0 Ct = 1.0 Ce = 1.0
Occupancy = Normal Thermal Conditions = Normally Heated/All Others
Snow Exposure = All Other Roof/Terrain Conditions
Roof Dead Load = 2 psf
